High density acoustic composite wall boards
HiGYP 30TM high density composite wall boards are designed to dramatically reduce airborne sound transmission through and down all types of masonry walls, with timber seperating floors. Patented acoustic FIBREfon Baffle Strips isolate the lining boards from the wall and provide a void to run services.
Related products
Cellecta C-Strip
YELOfon FS30
Cellecta AF100
HP30 Resilient Bar
Architect and specifier resources
Third Party Accreditation and Approvals
Specifications
Brand name
HiGYP 30TM
Product description
Acoustic composite wall lining board with high density facing
Thickness
30mm
Type of facing board
15mm thick high density gypsum
Resilient layer(s)
15mm thick LD woodfibre board
Board dimensions
600mm x 2400mm
Weight
15.9kg/m²- 45.79kg/unit
Flanking/edge strips
Cellecta C-Strip
Outstanding acoustic performance
Overall treatment only 45mm thick (30mm + 15mm)
Specifically for lining masonry walls with timber joist separating floor
Robust Detail and Proprietary applications
Handling and Storage
Store inside
This product should be stored inside on a pallet in water-tight conditions on a dry, flat and level base.
It can only be stored in a single lift, do not double stack.
If you are required to re-stack the product, we advise that the boards are stored on a pallet or are fully supported from the underside.
Care should be taken not to damage the edges of the board whilst re-stacking. The stacking of the product on it's edges should be avoided, as this can lead to damage.
Product protection
This product is supplied on pallets, wrapped in temporary protection. This covering is to offer dust protection and is a temporary measure to protect the boards from the weather during the loading/unloading process, it is not a waterproof cover and should be stored inside.
Adhesives and primers need to be protected from frost damage. They should be stored & used at temperatures between 5°C and 35°C and kept out of direct sunlight.
