Composite acoustic overlay floorboard
DECKfon 37T structural acoustic composite floorboards are designed to sit directly on timber floor joists. When combined with a new ceiling hung off metal resilient bars or acoustic hangers, provides oustanding and sound proofing.
Related products
YELOfon ES5
Cellecta FON Adhesive
FIBREfon Micro 50
HP30 Resilient Bar
Architect and specifier resources
Third Party Accreditation and Approvals
Specifications
Brand name
DECKfon 37T
Product description
Direct to joist, two layer acoustic floorboard
Type of facing board
22mm P5 T&G chipboard
Resilient layer
15mm open-cell polyurethane foam
Board dimensions (mm)
37 x 600 x 2400 (1.44m² coverage)
Weight
16.70kg/m², 24.05kg/board
Quantity per pallet
77.76m², 54 boards
Minimum order quantity
1 board
Associated acoustic perimeter edge strip required
YELOfon ES5/100
Required jointing adhesive
CELLECTA fon Adhesive
37mm board thickness
Over 200,000m² installed
Quick and easy to install
Robust Detail and Proprietary applications
Handling and Storage
Store inside
This product should be stored inside on a pallet in water-tight conditions on a dry, flat and level base.
It can only be stored in a single lift, do not double stack.
If you are required to re-stack the product, we advise that the boards are stored on a pallet or are fully supported from the underside.
Care should be taken not to damage the edges of the board whilst re-stacking. The stacking of the product on it's edges should be avoided, as this can lead to damage.
Product protection
This product is supplied on pallets, wrapped in temporary protection. This covering is to offer dust protection and is a temporary measure to protect the boards from the weather during the loading/unloading process, it is not a waterproof cover and should be stored inside.
Adhesives and primers need to be protected from frost damage. They should be stored & used at temperatures between 5°C and 35°C and kept out of direct sunlight.
